Technical principles
3
12000
6 m flags on a 12 m masts
10000
5 m flags on a 10 m masts
15
General presentation
© Renault Brand Stores - April 2016
Renault Store / Technical specifications for flags / Technical principles
Description
There are 2 mast heights in the dealership network: 10 m and
12 m.
The latter dimension is recommended for any new location.

6000
3500 3500

1500

5000
3500 3500

1500

Group of 3 flags Group of 5 flags
16
Assembly in single-brand site
© Renault Brand Stores - April 2016
Renault Store / Technical specifications for flags / Technical principles
Principle
The flags can be arranged in groups of 3 or 5, in the strict
sequences presented below.
675
1500
435
= =
= 1000 =
828
152
126
4459
1

2

17
Drawings of the 6,000 mm flags
© Renault Brand Stores - April 2016
Renault Store / Technical specifications for flags / Technical principles
Description
The flags are printed on 130 g/m2 white polyester
fabric.
A vector file (.eps) is available on the Brand Stores
website to ensure consistent reproduction.
Special attention shall be paid to:
• the regularity of the solid yellow colour,
• colour conformity,
• the regularity of the graduations in the diamond
which must be free of discontinuity lines.
Key
Brand signature in black on white background
Pantone yellow 7408 EC background
1 2
1500
6000
675
1500
435
= =
= 1000 =
828
152
126
3459
1
18
Drawings of the 5,000 mm flags
© Renault Brand Stores - April 2016
Renault Store / Technical specifications for flags / Technical principles
Description
The flags are printed on 130 g/m2 white polyester
fabric.
A vector file (.eps) is available on the Brand Stores
website to ensure consistent reproduction.
Special attention shall be paid to:
• the regularity of the solid yellow colour,
• colour conformity,
• the regularity of the graduations in the diamond
which must be free of discontinuity lines.
Key
Brand signature in black on white background
Pantone yellow 7408 EC background
1 2
1500

2

5000
10 m
ou 12 m
1500 mm
1 2 3 4 5
Description
The mast features a rotating-arm masthead so the
flag can be hung so as to always be visible even in
conditions without wind.
The mast is anchored to the ground on a concrete
block. The bottom of the mast is finished with an
attachment plate concealer.
To change the flag, the mast has to be tilted, this
being made possible by a hinged plate assembly.
The replacement operation - which can be frequent
depending on weather conditions - may require
several people.
Key
Rotary masthead arm
Flag guide ring
Counterweight to hold flag in windy conditions
Polyester masts, white RAL 9010
Attachment plate concealer
19
Tilting masts
© Renault Brand Stores - April 2016
Renault Store / Technical specifications for flags / Technical principles
1 2 3 4 5
The drawing opposite is given as an example. The
models of mast available on the market may differ
from the design opposite and may be protected by
patent or design model.
10 m
ou 12 m
1500 mm

1 2

3 4 5 6 7
20
Masts with halyard
Renault Store / Technical specifications for flags / Technical principles
Description
The mast features a rotating-arm masthead so the
flag can be hung.
The mast is anchored to the ground on a concrete
block. The bottom of the mast is finished with an
attachment plate concealer.
Flag change operations are facilitated by the
capability to lower and raise the flag supporting
section with the aid of the halyard internal to the
mast, accessible from the ground via a trap door.
The operation can be performed by one person.
Key
Rotary masthead arm
Flag supporting section
Flag guide ring
Counterweight to hold flag in windy conditions
Halyard access hatch
Polyester masts, white RAL 9010
Attachment plate concealer
© Renault Brand Stores - April 2016
1 2 3 4 5 6 7
The drawing opposite is given as an example. The
models of mast available on the market may differ
from the design opposite and may be protected by
patent or design model.
Group of 3 flags Group of 5 flags
21
Assembly in Renault Dacia multi-brand site
© Renault Brand Stores - April 2016
Renault Store / Technical specifications for flags / Technical principles
Principle
The flags can be arranged in groups of 3 or 5, in the strict
sequences presented below.
To manufacture the Dacia flags, refer to the
specifications and files available on the Bran
